2012 GALLARDO LP 570-4 SL - AUSTRALIA

Maintenance Parts:

Belts

PN	Item	Diagram
07L903137T	RIBBED V-BELT RIBBED V-BELT		Current Stock: 2 Our Price: $90.23

Brakes

PN	Item
400698151A	See PN 420698151F SET BRAKE	Avail to order Our Price: $1,206.64
400698151E	SET BRAKE LININGS SET BRAKE LININGS	Avail to order Our Price: $1,206.64
420698451B	REAR PAD SET GALLARDO LP560 SET BRAKE	Current Stock: 12 Our Price: $544.55
420698451D	E-BRAKE PAD SET GALLARDO LP560 SET BRAKE LININGS	Current Stock: 1 Our Price: $302.97
4E0698151G	See PN 4S0698151K Front Brake pads Set carbon ceramic brakes	Avail to order Our Price: $870.93

Drivetrain

PN	Item
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series	Avail to order Our Price: $89.92
07L105269J	Gallardo LP560 Clutch (Manual) CLUTCH FLYWHEEL (MANUAL GEARBOX) Gallardo LP560 Clutch (Manual)	Current Stock: 1 Our Price: $4,168.53
07L105269K	Balanced Clutch Assembly Egear 560 Balanced Clutch Assembly Egear 560	Current Stock: 6 Our Price: $5,322.32
07L105269M	See PN 07L105269K Complete Clutch Assembly LP560	Avail to order Our Price: $4,168.53
086141671K	SEE PN 086141671M CONCENTRIC SLAVE C	Avail to order Our Price: $842.64
086141671L	THROW OUT BEARING - EGEAR CONCENTRIC SLAVE CYLINDER IF REPLACING ORIGINAL 04-08 ALLARDO EQUIPMENT ALSO SEE PN: N10124306 X3	Avail to order Our Price: $2,114.04

Fuel-Air

PN	Item
0R1400313	LP560 and LP570 SERVICE KIT - Air-Cabin-OIL Filters Kit SERVICE KIT - 2 cabin, 2 air and 1 oil filter	Avail to order Our Price: $391.55
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $650.59
1J0907543A	TEMPERATURE SENSOR TEMPERATURE SENSOR	Current Stock: 1 Our Price: $46.31
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $131.32
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $289.31
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $85.46
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 1 Our Price: $120.44

Fuses-Bulbs-Relays

PN	Item
400941107	LIGHT LIGHT	Avail to order Our Price: $23.97
400945119D	FRONT LEFT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Current Stock: 2 Our Price: $316.18
400945120D	FRONT RIGHT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Avail to order Our Price: $316.18
N01713118	FUSE Please Check your Part Manual for a Description	Current Stock: 18 Our Price: $2.00
N10525502	FUSE STRIP FUSE STRIP	Avail to order Our Price: $6.11
N10566103	DISCHARGE LAMP DISCHARGE LAMP	Avail to order Our Price: $292.54

Ignition

PN	Item
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $422.55
07K905715F	PENCIL COIL PENCIL COIL	Avail to order Our Price: $85.01
101905631G	Spark Plug - Gallardo/Huracan LP Series Spark Plug Champion	Current Stock: 48 Our Price: $35.14
7P0915105	BATTERY BATTERY	Avail to order Our Price: $587.70

Misc

PN	Item
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
401955425C	WIPER BLADE (GALLARDO / MURCIELAGO) WIPER BLADE	Current Stock: 1 Our Price: $113.97
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item
059919523A	TEMPERATURE SENDER TEMPERATURE SENDER	Current Stock: 6 Our Price: $68.48
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $37.90
086141297	CLUTCH SENSOR CLUTCH SENSOR	Avail to order Our Price: $497.25
086927321	Crank/Flywheel/Timing Sensor ELECTROMAGNETIC PROBE	Avail to order Our Price: $126.55
1K2945511	SWITCH,BRAKE PEDAL SWITCH,BRAKE PEDAL	Avail to order Our Price: $28.44
400698137	Worn Pads Sensor Worn Pads Sensor	Current Stock: 2 Our Price: $123.42
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $46.75
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $46.75
4F0907275D	See PN 7PP907275F WHEEL ELECTRONICS	Avail to order Our Price: $203.22

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 907.02.00 - ELECTRICAL SYSTEM

2012 Lamborghini GALLARDO LP 570-4 SL AUSTRALIA ELECTRICAL SYSTEM (907.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	400907552G	CONTROL UNIT LIE CONTROL UNIT - 4WD (NOT FOR A MARKET SCANDINAVIA - ORDER ALSO REF. 4 - 7)	2 req	Avail to order Our Price: $5,917.83
2	N91073301	SEE PN N91096601 SCREW M6X12	6 req	Avail to order Our Price: $2.00
3	408907324A	BRACKET RH BRACKET	1 req	Avail to order Our Price: $1,232.69
3	408907348B	BRACKET LH BRACKET	1 req	Avail to order Our Price: $95.59
4	N91023802	SHEAR BOLT SCREW M5X14	4 req	Current Stock: 10 Our Price: $2.00
5	8E0907411J	PROTECTION HOUSING BRACKET	2 req	Avail to order Our Price: $61.56
6	420907637	SENSOR YAWRATE SENSOR (ESP)	1 req	Avail to order Our Price: $1,161.24
7	N90980304	SHEAR BOLT SCREW M6X12	4 req	Current Stock: 9 Our Price: $2.00
8	400927156D	CONTROL UNIT E-GEAR CONTROL UNIT (4WD)	1 req	Avail to order Our Price: $7,845.77
9	8E0907500J	CATCH BRACKET	2 req	Current Stock: 1 Our Price: $39.68
10	408907354A	BRACKET LH BRACKET	1 req	Avail to order Our Price: $16.16
10	408907649A	BRACKET RH BRACKET	1 req	Avail to order Our Price: $16.16
11	408907347B	BRACKET BRACKET (E-GEAR)	1 req	Avail to order Our Price: $32.91
12	N01508213	HEXAGON FLANGE NUT NUT M6	4 req	Current Stock: 4 Our Price: $2.00
13	N01508213	HEXAGON FLANGE NUT NUT M6	2 req	Current Stock: 4 Our Price: $2.00
14	8P0035503M	ANTENNA ANTENNA BLUETOOTH	1 req	Avail to order Our Price: $31.79
15	408862399	COVER BRACKET (BLUETOOTH CONTROL UNIT)	1 req	Avail to order Our Price: $45.70
16	N01508213	HEXAGON FLANGE NUT NUT M6	2 req	Current Stock: 4 Our Price: $2.00
17	N01508213	HEXAGON FLANGE NUT NUT M6	2 req	Current Stock: 4 Our Price: $2.00
18		CD CHANGER (SEE TABLE 857.07.00)	0 req
19	400980655	NLA (No Longer Available) AIRBAG SENSOR	2 req	*See Description
20		BRACKET (VALID UP TO MODEL YEAR 10)	0 req
21	N91020102	HEXALOBULAR SOCKET SCREW M6X14	6 req	Avail to order Our Price: $2.00
22		TV-TUNER (SEE TABLE 857.07.00)	0 req
23	408035643B	BRACKET SUPPORT	1 req	Avail to order Our Price: $163.02
24	N91073301	SEE PN N91096601 SCREW M6X12	7 req	Avail to order Our Price: $2.00
25	N10227805	PAN HEAD BOLT WITH WASHER SCREW M6X20	2 req	Avail to order Our Price: $2.00
26	N01508213	HEXAGON FLANGE NUT NUT M6	1 req	Current Stock: 4 Our Price: $2.00
27	420971845R	BRACKET BRACKET	1 req	Avail to order Our Price: $21.15
28	8P1862335A	CELLULAR PHONE BLUETOOTH CONTROL UNIT	1 req	Avail to order Our Price: $803.94
29	N91020102	HEXALOBULAR SOCKET SCREW M6X14	2 req	Avail to order Our Price: $2.00
30	N10595002	HEXALOBULAR SOCKET SCREW M5X18	2 req	Avail to order Our Price: $2.00
31	4F0937503	RELAY PLATE SUPPORT (ENGINE RELAY BOX WIRING HARNESS)	1 req	Avail to order Our Price: $11.99
32	N01508213	HEXAGON FLANGE NUT NUT M6	2 req	Current Stock: 4 Our Price: $2.00
33	4F1971845A	BRACKET SUPPORT	1 req	Avail to order Our Price: $14.90
34	4F1937545	CLUTCH CARRIER SUPPORT (CENTRAL WIRING HARNESS)	1 req	Avail to order Our Price: $7.22
35	N10597201	HEX.NUT W/ FLANGE NUT M5	2 req	Avail to order Our Price: $2.31
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
