2011 GALLARDO LP 570-4 SL - ENGLAND

Maintenance Parts:

Belts

PN	Item	Diagram
07L903137T	RIBBED V-BELT RIBBED V-BELT		Current Stock: 2 Our Price: $90.23

Brakes

PN	Item
4E0698151G	See PN 4S0698151K Front Brake pads Set carbon ceramic brakes	Avail to order Our Price: $870.93
400698151A	See PN 420698151F SET BRAKE	Avail to order Our Price: $1,206.64
420698451D	E-BRAKE PAD SET GALLARDO LP560 SET BRAKE LININGS	Current Stock: 1 Our Price: $302.97
420698451B	REAR PAD SET GALLARDO LP560 SET BRAKE	Current Stock: 12 Our Price: $544.55
400698151E	SET BRAKE LININGS SET BRAKE LININGS	Avail to order Our Price: $1,206.64

Drivetrain

PN	Item
07L105269J	Gallardo LP560 Clutch (Manual) CLUTCH FLYWHEEL (MANUAL GEARBOX) Gallardo LP560 Clutch (Manual)	Current Stock: 1 Our Price: $4,168.53
07L105269K	Balanced Clutch Assembly Egear 560 Balanced Clutch Assembly Egear 560	Current Stock: 6 Our Price: $5,322.32
086141671L	THROW OUT BEARING - EGEAR CONCENTRIC SLAVE CYLINDER IF REPLACING ORIGINAL 04-08 ALLARDO EQUIPMENT ALSO SEE PN: N10124306 X3	Avail to order Our Price: $2,114.04
086141671K	SEE PN 086141671M CONCENTRIC SLAVE C	Avail to order Our Price: $842.64
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series	Avail to order Our Price: $89.92
07L105269M	See PN 07L105269K Complete Clutch Assembly LP560	Avail to order Our Price: $4,168.53

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $131.32
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $85.46
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 1 Our Price: $120.44
1J0907543A	TEMPERATURE SENSOR TEMPERATURE SENSOR	Current Stock: 1 Our Price: $46.31
0R1400313	LP560 and LP570 SERVICE KIT - Air-Cabin-OIL Filters Kit SERVICE KIT - 2 cabin, 2 air and 1 oil filter	Avail to order Our Price: $391.55
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $289.31
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $650.59

Fuses-Bulbs-Relays

PN	Item
N10525502	FUSE STRIP FUSE STRIP	Avail to order Our Price: $6.11
N01713118	FUSE Please Check your Part Manual for a Description	Current Stock: 18 Our Price: $2.00
N10566103	DISCHARGE LAMP DISCHARGE LAMP	Avail to order Our Price: $292.54
400941107	LIGHT LIGHT	Avail to order Our Price: $23.97
400945119D	FRONT LEFT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Current Stock: 2 Our Price: $316.18
400945120D	FRONT RIGHT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Avail to order Our Price: $316.18

Ignition

PN	Item
7P0915105	BATTERY BATTERY	Avail to order Our Price: $587.70
101905631G	Spark Plug - Gallardo/Huracan LP Series Spark Plug Champion	Current Stock: 48 Our Price: $35.14
07K905715F	PENCIL COIL PENCIL COIL	Avail to order Our Price: $85.01
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $422.55

Misc

PN	Item
401955425C	WIPER BLADE (GALLARDO / MURCIELAGO) WIPER BLADE	Current Stock: 1 Our Price: $113.97
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27

Sensors

PN	Item
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $37.90
4F0907275D	See PN 7PP907275F WHEEL ELECTRONICS	Avail to order Our Price: $203.22
059919523A	TEMPERATURE SENDER TEMPERATURE SENDER	Current Stock: 6 Our Price: $68.48
086141297	CLUTCH SENSOR CLUTCH SENSOR	Avail to order Our Price: $497.25
086927321	Crank/Flywheel/Timing Sensor ELECTROMAGNETIC PROBE	Avail to order Our Price: $126.55
400698137	Worn Pads Sensor Worn Pads Sensor	Current Stock: 2 Our Price: $123.42
1K2945511	SWITCH,BRAKE PEDAL SWITCH,BRAKE PEDAL	Avail to order Our Price: $28.44
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $46.75
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $46.75

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 505.06.00 - REAR ARMS

2011 Lamborghini GALLARDO LP 570-4 SL ENGLAND REAR ARMS (505.06.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N10716901	HEXAGON FLANGE SCREW M12X1.5X170X90	2 req	Avail to order Our Price: $13.33
2	400501429	MOUNTING LEFT SUPPORT	1 req	Avail to order Our Price: $55.69
2	400501430	MOUNTING RIGHT SUPPORT	1 req	Avail to order Our Price: $55.69
3	420501429E	MOUNTING LEFT SUPPORT	1 req	Avail to order Our Price: $60.15
3	420501430E	MOUNTING RIGHT SUPPORT	1 req	Avail to order Our Price: $60.15
4	WHT004898	HEXAGON FLANGE NUT W.WASHER NUT M14X1.5 (FROM VIN BLA11071)	2 req	Current Stock: 14 Our Price: $6.48
4		KIT REAR AXLE (UNTIL THE VIN BLA11070 - SEE REF. 5)	1 req
4	N90848406	HEXAGON FLANGE NUT NUT M12X1.5 (FROM VIN BLA10486 )	2 req	Current Stock: 4 Our Price: $7.67
4	N90848404	HEXAGON NUT W. NUT M12X1.5 (UNTIL THE VIN BLA10485 )	2 req	Current Stock: 2 Our Price: $4.69
5	400505323F	TRACK CONTROL ARM LH UPPER ARM (UNTIL THE VIN BLA10485 )	1 req	Avail to order Our Price: $725.03
5	400505323H	TRACK CONTROL ARM LH UPPER ARM (FROM VIN BLA10486 )	1 req	Avail to order Our Price: $725.03
5	400505324F	TRACK CONTROL ARM RH UPPER ARM (UNTIL THE VIN BLA10485 )	1 req	Avail to order Our Price: $725.03
5	400505324H	RH UPPER ARM (FROM VIN BLA10486 )	1 req
5	0R1400560	M14 REAR SUSPENSION ARMS KIT KIT REAR AXLE (UNTIL THE VIN BLA11070 - INCLUDES: LH RH UPPER LOWER ARM - NUT M14 - REAR LH RH HUB CARRIER)	1 req	Avail to order Our Price: $3,485.14
5	400505323J	TRACK CONTROL ARM LH UPPER ARM (FROM VIN BLA11071)	1 req	Avail to order Our Price: $699.72
5	400505324J	TRACK CONTROL ARM RH UPPER ARM (FROM VIN BLA11071)	1 req	Avail to order Our Price: $699.72
6	N10689301	12-POINT SOCKET SCREW M8X25	4 req	Current Stock: 4 Our Price: $3.28
7	N10689301	12-POINT SOCKET SCREW M8X25	4 req	Current Stock: 4 Our Price: $3.28
8		FLEXIBLE BUSHING (CANNOT BE SOLD SEPARATELY - SEE REF. 5 - 10)	0 req
9	420501429M	MOUNTING LEFT SUPPORT	1 req	Current Stock: 1 Our Price: $60.15
9	420501430M	MOUNTING RIGHT SUPPORT	1 req	Avail to order Our Price: $60.15
10	400505311J	TRACK CONTROL ARM LH LOWER ARM (FROM VIN BLA11071)	1 req	Avail to order Our Price: $655.06
10	400505312J	TRACK CONTROL ARM RH LOWER ARM (FROM VIN BLA11071)	1 req	Avail to order Our Price: $655.06
10		KIT REAR AXLE (UNTIL THE VIN BLA11070 - SEE REF. 5)	1 req
10	400505311F	TRACK CONTROL ARM LH LOWER ARM (UNTIL THE VIN BLA10485 )	1 req	Avail to order Our Price: $672.92
10	400505311H	TRACK CONTROL ARM LH LOWER ARM (FROM VIN BLA10486 )	1 req	Avail to order Our Price: $689.30
10	400505312F	TRACK CONTROL ARM RH LOWER ARM (UNTIL THE VIN BLA10485 )	1 req	Avail to order Our Price: $672.92
10	400505312H	RH LOWER ARM (FROM VIN BLA10486 )	1 req
11	400511409H	stabilizer REAR STABILIZER BAR	1 req	Avail to order Our Price: $409.41
12	4D0411327G	RUBBER MOUNTING BUSHING	2 req	Current Stock: 1 Our Price: $15.63
13	420411031A	STABILIZER MOUNTIN STABILIZER BAR BRACKET	2 req	Avail to order Our Price: $27.02
14	N10682501	12-POINT SOCKET FL SCREW M8X50	4 req	Current Stock: 6 Our Price: $2.90
15	400501429A	MOUNTING LEFT SUPPORT	1 req	Avail to order Our Price: $55.69
15	400501430A	MOUNTING RIGHT SUPPORT	1 req	Avail to order Our Price: $55.69
16	420505465	CONNECTING LINK CONNECTING ROD	2 req	Avail to order Our Price: $175.68
17	420407457F	MOUNTING RIGHT SUPPORT	1 req	Avail to order Our Price: $613.37
17	420407458F	MOUNTING LEFT SUPPORT	1 req	Avail to order Our Price: $613.37
18	N10272302	HEX.NUT W/ FLANGE NUT M10	2 req	Avail to order Our Price: $2.46
20	N10106402	HEX.NUT W/FLANGE LOCKING ELEM. NUT M12X1.5	2 req	Avail to order Our Price: $2.61
21	420407457F	MOUNTING LEFT SUPPORT	1 req	Avail to order Our Price: $613.37
21	420407458F	MOUNTING RIGHT SUPPORT	1 req	Avail to order Our Price: $613.37
22	WHT002262	ECCENTRIC BOLT SCREW M12X1.5X87	2 req	Avail to order Our Price: $16.60
23	WHT003176	ECCENTRIC BOLT SCREW M12X1.5X125	2 req	Avail to order Our Price: $18.25
24	WHT001676	ECCENTRIC WASHER WASHER	4 req	Current Stock: 6 Our Price: $1.94
25	N10106402	HEX.NUT W/FLANGE LOCKING ELEM. NUT M12X1.50	4 req	Avail to order Our Price: $2.61
26	N10428002	HEXAGON FLANGE SCREW M12X1.5X80	4 req	Avail to order Our Price: $6.70
27	4D0411336G	CLIP STABILIZER BAR BRACKET	2 req	Current Stock: 1 Our Price: $5.74
28	WHT004898	HEXAGON FLANGE NUT W.WASHER NUT M14X1.5 (FROM VIN BLA11071)	2 req	Current Stock: 14 Our Price: $6.48
28		KIT REAR AXLE (UNTIL THE VIN BLA11070 - SEE REF. 5)	1 req
28	N90848404	HEXAGON NUT W. NUT M12X1.5 (UNTIL THE VIN BLA10485 )	2 req	Current Stock: 2 Our Price: $4.69
28	N90848406	HEXAGON FLANGE NUT NUT M12X1.5 (FROM VIN BLA10486 )	2 req	Current Stock: 4 Our Price: $7.67
29	N90848406	HEXAGON FLANGE NUT NUT M12X1.5	2 req	Current Stock: 4 Our Price: $7.67
30		CONNECTING ROD (VALID UP TO MODEL YEAR 10 )	0 req
31	400512019AP	DAMPER STRUT SHOCK ABSORBER (STANDARD/LIFTING SYSTEM - UNTIL THE VIN ALA09701 REPLACE PER AXLE)	2 req	Avail to order Our Price: $2,990.56
31	400512019BA	DAMPER STRUT SHOCK ABSORBER (SPORT/LIFTING SYSTEM)	2 req	Avail to order Our Price: $1,373.28
32	N10428002	HEXAGON FLANGE SCREW M12X1.5X80	2 req	Avail to order Our Price: $6.70
33	N10106402	HEX.NUT W/FLANGE LOCKING ELEM. NUT M12X1.5	2 req	Avail to order Our Price: $2.61
34	4E0971845AR	BRACKET BRACKET	2 req	Avail to order Our Price: $8.87
35	N10082911	HEX. BOLT WITH WASHER SCREW M6X16	2 req	Current Stock: 2 Our Price: $2.00
36	420501530C	TIE ROD CONNECTING ROD	2 req	Avail to order Our Price: $640.17
36	420501530C	TIE ROD CONNECTING ROD (FROM VIN ALA09566)	2 req	Avail to order Our Price: $640.17
37	N10695901	HEXAGON FLANGE BOL SCREW BM12X1.50X105X90 (FROM VIN ALA09566)	2 req	Current Stock: 1 Our Price: $10.05
38		REAR HUB CARRIER (SEE TABLE 505.04.00)	0 req
39	N10425302	HEXAGON FLANGE SCREW M10X62X45	2 req	Avail to order Our Price: $6.33
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
