TAV: 11.01.00 - Right Cylinder Head

1999 Lamborghini Diablo 2WD-4WD USA Right Cylinder Head (11.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008200605	NLA (No Longer Available)	1 req	*See Description
2	WHT001197A	WASHER	1 req	Current Stock: 2 Our Price: $2.00
3	008300650	Special Stud M6x51	1 req	Avail to order Our Price: $13.57
4	460132000	RH Machined Head MY98	1 req	Avail to order Our Price: $19,395.28
5	WHT003019	Bushing 6.25x8x10 mm	2 req	Current Stock: 2 Our Price: $12.36
6	N01100637	HEX.NUT	28 req	Current Stock: 18 Our Price: $2.00
7	WHT001197A	WASHER	28 req	Current Stock: 2 Our Price: $2.00
8	008300666	No Description - Please Check your book	28 req	Avail to order Our Price: $47.86
9	008840802	Heli-Coil M8x1.25 L12	12 req	Avail to order Our Price: $3.58
10	008931409	Casting Plug	2 req	Avail to order Our Price: $13.94
11	001232709	NLA (No Longer Available)	1 req	*See Description
12	07M109022	Intake Camshaft	1 req	Avail to order 1 Used Available Our Price: $9,550.40
13	001122089	Manifold Centring Dowel	2 req	Current Stock: 2 Our Price: $19.01
14	07M109320	Valve Adjustment Shim 3.25 mm	24 req	Current Stock: 51 Our Price: $11.77
14	07M109320A	Valve Adjustment Shim 3.30 mm	24 req	Current Stock: 67 Our Price: $11.77
14	07M109320B	Valve Adjustment Shim 3.35 mm	24 req	Current Stock: 60 Our Price: $58.21
14	07M109320C	Valve Adjustment Shim 3.40 mm	24 req	Current Stock: 55 Our Price: $55.02
14	07M109320D	Valve Adjustment Shim 3.45 mm	24 req	Current Stock: 35 Our Price: $11.77
14	07M109320E	Valve Adjustment Shim 3.50 mm	24 req	Current Stock: 58 Our Price: $58.21
14	07M109320F	Valve Adjustment Shim 3.55 mm	24 req	Current Stock: 6 Our Price: $11.77
14	07M109320G	Valve Adjustment Shim 3.60 mm	24 req	Avail to order Our Price: $58.21
14	07M109320H	Valve Adjustment Shim 3.65 mm	24 req	Current Stock: 2 Our Price: $60.44
14	07M109320J	Valve Adjustment Shim 3.70 mm	24 req	Current Stock: 2 Our Price: $58.21
14	07M109320K	Valve Adjustment Shim 3.75 mm	24 req	Avail to order Our Price: $58.21
14	07M109320L	Valve Adjustment Shim 3.80 mm	24 req	Current Stock: 56 Our Price: $58.21
14	07M109320M	Valve Adjustment Shim 3.85 mm	24 req	Current Stock: 24 Our Price: $11.77
14	07M109320N	Valve Adjustment Shim 3.90 mm	24 req	Current Stock: 32 Our Price: $58.21
14	07M109320P	Valve Adjustment Shim 3.95 mm	24 req	Current Stock: 29 Our Price: $58.21
14	07M109320Q	Valve Adjustment Shim 4.00 mm	24 req	Current Stock: 43 Our Price: $85.61
14	07M109320R	Valve Adjustment Shim 4.05 mm	24 req	Current Stock: 24 Our Price: $11.77
14	07M109320S	Valve Adjustment Shim 4.10 mm	24 req	Current Stock: 41 Our Price: $58.21
14	07M109320T	Valve Adjustment Shim 4.15 mm	24 req	Current Stock: 40 Our Price: $11.77
14	07M109320AA	Valve Adjustment Shim 4.20 mm	24 req	Current Stock: 59 Our Price: $11.77
14	07M109320AB	Valve Adjustment Shim 4.25 mm	24 req	Current Stock: 83 Our Price: $11.77
14	07M109320AC	Valve Adjustment Shim 4.30 mm	24 req	Current Stock: 50 Our Price: $11.77
14	07M109320AD	Valve Adjustment Shim 4.35 mm	24 req	Current Stock: 70 Our Price: $11.77
14	07M109320AE	Valve Adjustment Shim 4.40 mm	24 req	Current Stock: 73 Our Price: $58.21
14	07M109320AF	Valve Adjustment Shim 4.45 mm	24 req	Current Stock: 58 Our Price: $11.77
14	07M109320AG	Valve Adjustment Shim 4.50 mm	24 req	Current Stock: 62 Our Price: $11.77
14	07M109320AH	Valve Adjustment Shim 4.55 mm	24 req	Current Stock: 69 Our Price: $11.77
14	07M109320AJ	Valve Adjustment Shim 4.60 mm	24 req	Current Stock: 17 Our Price: $11.77
14	07M109320AK	Valve Adjustment Shim 4.65 mm	24 req	Current Stock: 28 Our Price: $11.77
14	07M109320AL	Valve Adjustment Shim 4,70 mm	24 req	Current Stock: 33 Our Price: $11.77
15	07M109309	Valve Bowl	24 req	Avail to order Our Price: $38.34
16	07M109651	Valve Seal Cotter	48 req	Current Stock: 9 Our Price: $2.00
17	07M109641	Spring Upper Washer	24 req	Avail to order Our Price: $19.95
18	07M109633A	Inner Valve Spring	24 req	Avail to order Our Price: $6.48
19	07M109623A	Valve Spring	24 req	Avail to order Our Price: $19.95
20	07M109642	Spring Lower Washer	24 req	Avail to order Our Price: $18.54
21	07M109675	Valve Guide Rubber Pad	24 req	Current Stock: 51 Our Price: $16.46
22	001238321	No Description - Please Check your book	12 req	Current Stock: 4 Our Price: $79.92
23	07M109601	Intake Valve	12 req	Current Stock: 3 Our Price: $75.79
24	07M103431	Intake Valve Seat	12 req	Current Stock: 12 Our Price: $49.95
25	001238320	No Description - Please Check your book	12 req	Current Stock: 3 Our Price: $98.25
26	07M109611	Exhaust Valve	12 req	Current Stock: 22 Our Price: $108.83
27	07M103441	Exhaust Valve Seat	12 req	Current Stock: 12 Our Price: $45.19
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
